| INA PART NO. | VLU200844-N |
| MAS PART NO. | M VLU200844-N |
| SERIES | VL |
| GEAR | Without gear |
| TYPE | Ball |
| System of Measurement | Metric |
| Internal Diameter(mm) | 734 |
| Outside Diameter(mm) | 948 |
| Internal Diameter On Outer Ring Di(mm) | 845.5 |
| External Diameter On Inner Ring do(mm) | 842.5 |
| Height of Overall Bearing Assembly H（mm) | 56 |
| Weight(kg) | 48 |
| Bolt Circle In Out Ring Lo(mm) | 920 |
| NO.Holes In Out Ring no | 14 |
| Bolt Circle In Inner Ring Li(mm) | 762 |
| NO.Holes In Inner Ring ni | 18 |
| dizt(mm) | 736 |
| D azt(mm) | 946 |
| Maximum Allowable Radial Load | 109200 N |
| Basic Dynamic Load Rating Axial (Ca) | 182000 N |
| Basic Static Load Rating Axial (C0a) | 600000 N |
| Basic Dynamic Load Rating Radial(Cr) | 164000 N |
| Basic Dynamic Load Rating Radial(COr) | 224000 N |
| Taper Type Lubrication Nipples | 4 |
| Bearings Are Also Available Without Holes In The Bearing Rings | Yes |
